NTT-AT Optical Connector Cleaner NEOCLEAN®-M/NEOCLEAN®-M2

NTT-AT Optical Connector Cleaner NEOCLEAN®-M/NEOCLEAN®-M2

Instantly clean MPO connectors with a simple push

Many troubles in optical communications equipment are caused by contamination on the optical connector end face.
NEOCLEAN-M series, the MPO/MTP connector cleaners, employ microfibers designed specifically for optical connectors to remove even the smallest contamination not visible to the naked eye. Please take advantage of the improvements you will receive in optical construction working efficiency and in communication services reliability.

MPO connectors of 1 row with 12 core and 2 rows with 24 core are common, and the MPO-16 expanded to 1 row with 16 care has been introduced, and so the importance of cleaning is also increasing.
The NEOCLEAN-M for 12-core systems and the NEOCLEAN-M2 for 16-core systems respond to the need for endface cleaning.

Specifications:

Product Name		NEOCLEAN-M	NEOCLEAN-M2
Model		ATC-NE-M1	ATC-NE-M2
Compatible Connectors		MPO, MTP®	MPO-16, MTP® -16
Compatible End Face		Flat and 8 degree slant (compatible with or without guide pins)
Size(mm)	Main Body	197L×15W×51H	197L×15W×51H
	With Cap Attached	208L×17W×51H	204L×15W×51H
Standard Usages		Over 600 times
