200X Video Inspection Probe USB OFT-200U
OFT-200U is the digital probe with USB function to connect the laptop or PC directly, which includes image sensor inside the probe to have real-time inspection, no need for any additional power cord and driver for installation. It’s most suitable for use by fiber operators and research institutions.
Probe Highlights
● Consistent alignment, simple to operate
● 200×, High definition, clear image
● 40+ tips suitable for single/dual mode to have PC/APC inspection
● Adjusted source light inside, easy for detection
Standard Tips:
2.5-U-M,1.25-U-M,SC-U-F,LC-U-F
Specification:
|
Magnification： |
200X |
|
Definition： |
0.5μm |
|
Focus： |
Manual |
|
CCD Sensor： |
1/3"420 Line |
|
Output Type： |
USB |
|
Storage Temperature： |
-20~50℃ |
|
Operational Temperature： |
-10~50℃ |
|
Powe Consumption： |
3W |
|
Power Adaptor： |
USB 5V |
|
Communication Port： |
USB |
|
Dimension： |
210mm*56mm*50mm |
|
Weight： |
0.5kg |
Fiber Optic Video Microscope O
Inspection of fiber termination,patch cords,pigtails,and cable assemblies....
