VFL-Visual Fault Locator

  • Fiber Optic Visual Fault Locator VFL-650
Fiber Optic Visual Fault Locator VFL-650

Fiber Optic Visual Fault Locator VFL-650

  • Product description: VFL-650 is an indispensable tool in fiber engineering construction, fiber network maintenance, optical device production and research.
  • INQUIRY

Fiber Optic Visual Fault Locator VFL-650

VFL-650 comes with a 650nm semiconductor laser is used as a light emitting device, which is driven by a constant current source, emits a stable red light and enters a multimode and single mode fiber after connecting with the optical interface to realize the fiber fault detection function. it is an indispensable tool in fiber engineering construction, fiber network maintenance, optical device production and research.

Features:

Adopt new ergonomics design; support adjustable luminous power; support alkaline battery, portable battery, computer, adapter, lithium battery power supply mode; support lighting function, convenient field, machine room, night and other dark environment to check the line construction.

Technical indicators:

Model

VFL-650-05

VFL-650-10

VFL-650-15

VFL-650-20

VFL-650-30

Output power

>5 mW

mW >10

mW >15

mW >20

mW >30

Working current

≤40 mA

mA≤140

mA≤150

mA≤160

mA≤170

Duration

h >10

>3.5 h

>5 h

Charge time

Uncharged

h≤3

≤5 h

Charge current

mA≤300

Charging voltage

5V

Static current

uA≤15

Gear output

Not switched

Can switch three gears

Output wavelength

650 nm

Interface type

2.5 mm Universal adapters

Working temperature

-20~+60℃(not exposed)

Storage temperature

-40~+85℃

Type of power

2 7 alkaline batteries or lithium batteries (optional)

Product size

125*35*17 mm

Packing size

150*60*30 mm

Net

56 g

Total

83 g
